Defines topological vertex. More...

Inheritance diagram for cadex.ModelData.Vertex:

Public Member Functions
	Vertex (global::System.IntPtr cPtr, bool cMemoryOwn)

	Vertex (cadex.Geom.Point thePoint)

cadex.Geom.Point	Point ()
	Returns a 3D point this vertex resides at.

void	SetTolerance (double theTolerance)
	Sets vertex tolerance.

double	Tolerance ()
	Returns vertex tolerance.

Public Member Functions inherited from cadex.ModelData.Shape
	Shape (global::System.IntPtr cPtr, bool cMemoryOwn)

override int	GetHashCode ()

cadex.ModelData.ShapeType	Type ()
	Returns a shape type. For a null object returns Undefined.

cadex.ModelData.ShapeOrientation	Orientation ()
	Returns orientation flag.

cadex.ModelData.Shape	Reversed ()
	Returns a shape that shares the same geometry and subshape graph but has opposite orientation.

cadex.ModelData.Shape	Oriented (cadex.ModelData.ShapeOrientation theOrientation)
	Returns a shape that shares the same geometry and subshape graph and has specified orientation.

bool	IsEqual (cadex.ModelData.Shape theOther)
	Returns true if the shape shares the same geometry and subshape graph, and has equal orientation.

bool	IsSame (cadex.ModelData.Shape theOther)
	Returns true if the shape shares the same geometry and subshape graph.

void	SetName (cadex.UTF16String theName)
	Sets the name.

cadex.UTF16String	Name ()
	Returns the name.

void	AddAssociatedPMI (cadex.PMI.Element theElement)
	Adds the PMI element.

void	AddAssociatedPMI (cadex.Collections.PMIElementList theElements)
	Adds the PMI elements.

cadex.Collections.PMIElementList	AssociatedPMI ()
	Returns the PMI elements.

override bool	Equals (System.Object o)

Public Member Functions inherited from cadex.BaseObject
	BaseObject (global::System.IntPtr cPtr, bool cMemoryOwn)

void	Dispose ()

bool	IsNull ()

ulong	Id ()
	Return unique identifier of public object.

bool	IsEqual (cadex.BaseObject theObj)

override int	GetHashCode ()

override bool	Equals (System.Object o)

Static Public Member Functions
static cadex.ModelData.Vertex	Cast (cadex.ModelData.Shape theShape)

static new bool	CompareType (cadex.BaseObject theObject)
	Check the type of object. Returns true if the specified object is this class type.

Static Public Member Functions inherited from cadex.ModelData.Shape
static bool	CompareType (cadex.BaseObject theObject)
	Check the type of object. Returns true if the specified object is this class type.

static cadex.ModelData.Shape	Cast (cadex.BaseObject theBase)

Protected Member Functions
override void	Dispose (bool disposing)

Detailed Description

Defines topological vertex.

The following image depicts an example of a vertex:

Vertex

A vertex resides on a geometrical 3D point returned by Point().

Tolerance

The vertex tolerance (returned by Tolerance()) defines a radius of a radius of a sphere around the vertex point, in which ends of all connecting edges must reside. The tolerance must be equal to greater to tolerance of connecting edges.

Any vertex is created with a default tolerance of 1e-7mm. The tolerance must be equal to greater to tolerance of all connecting edges.
