cadex::Machining_Bore Class Reference

Describes a machining bore. More...

Inheritance diagram for cadex::Machining_Bore:

Public Types
typedef std::shared_ptr< internal::MachiningImpl_Bore >	ImplType
Public Types inherited from cadex::MTKBase_ShapeFeature
typedef cadex::internal::MTKBaseImpl_ShapeFeature	ImplType
typedef std::shared_ptr< ImplType >	ImplPtrType
Public Types inherited from cadex::MTKBase_Feature
typedef cadex::internal::MTKBaseImpl_Feature	ImplType
typedef std::shared_ptr< ImplType >	ImplPtrType

Public Member Functions
	Machining_Bore ()
	Constructor.
	Machining_Bore (double theDepth, double theWidth)
	Constructor.
double	Depth () const
	Returns the bore depth in mm .
void	SetDepth (double theDepth)
	Sets the bore depth in mm .
double	Radius () const
	Returns the bore radius in mm .
void	SetRadius (double theWidth)
	Sets the bore radius in mm .
const ModelData::Shape &	Sidewalls () const
	Returns the shape containing the bore sidewalls.
void	SetSidewalls (const ModelData::Shape &theSidewalls)
	Sets the shape for bore sidewalls.
const ModelData::Shape &	Bottom () const
	Returns the bottom shape of the bore.
void	SetBottom (const ModelData::Shape &theBottom)
	Sets the shape for the bore bottom.
Public Member Functions inherited from cadex::MTKBase_ShapeFeature
	MTKBase_ShapeFeature ()
	Constructor.
	MTKBase_ShapeFeature (const ModelData::Shape &theShape)
	Constructor.
const ModelData::Shape &	Shape () const
	Returns shape of the feature.
void	SetShape (const ModelData::Shape &theShape)
	Sets shape of the feature.
Public Member Functions inherited from cadex::MTKBase_Feature
	MTKBase_Feature ()
	Constructor.
	~MTKBase_Feature ()
	Destructor.
void	Nullify ()
	Resets reference to implementation object.
bool	IsNull () const
	Returns true if the object is nullified.
	operator bool () const
	Casts the object to the bool type.
template<typename T >
bool	IsOfType () const
ImplType *	Impl () const
template<typename T >
T *	Impl () const
	Reserved for internal use.
bool	operator== (const MTKBase_Feature &theObject) const
bool	operator!= (const MTKBase_Feature &theObject) const

Static Public Member Functions
static bool	CompareType (const MTKBase_Feature &theFeature)
	Returns true if theFeature is a machining bore.
Static Public Member Functions inherited from cadex::MTKBase_ShapeFeature
static bool	CompareType (const MTKBase_Feature &theFeature)
	Returnstrue if theFeature is a shape feature.

Protected Member Functions
	Machining_Bore (ImplType theImpl)
	Reserved for internal use.
Protected Member Functions inherited from cadex::MTKBase_ShapeFeature
	MTKBase_ShapeFeature (ImplPtrType theImpl)
	Reserved for internal use.
Protected Member Functions inherited from cadex::MTKBase_Feature
	MTKBase_Feature (ImplPtrType theImpl)
	Reserved for internal use.

Additional Inherited Members
Protected Attributes inherited from cadex::MTKBase_Feature
ImplPtrType	myImpl

Detailed Description

Describes a machining bore.

A bore feature is formed by enlarging an existing hole using a rigid single-point cutting tool. It consists of one or more faces defining an internal cylindrical surface, optionally with a bottom. Precision is determined by the rigidity of the spindle and the boring tool. Horizontal boring ensures accurate internal geometry with the workpiece moving parallel to the tool's axis.

Examples

machining/feature_recognizer/Program.cs, and machining/feature_recognizer/main.cxx.

Constructor & Destructor Documentation

Machining_Bore() [1/3]

cadex::Machining_Bore::Machining_Bore

(

)

Constructor.

Machining_Bore() [2/3]

cadex::Machining_Bore::Machining_Bore	(	double	theDepth,
		double	theRadius )

Constructor.

Creates the machining bore from the depth and radius.

Machining_Bore() [3/3]

cadex::Machining_Bore::Machining_Bore ( ImplType theImpl )

explicitprotected

Reserved for internal use.

Constructor.

For internal use.

Member Function Documentation

Bottom()

const ModelData::Shape & cadex::Machining_Bore::Bottom

(

)

const

Returns the bottom shape of the bore.

The shape can be a single face or shell. Returns a null shape if the bore has no bottom.

See also

SetBottom()

CompareType()

bool cadex::Machining_Bore::CompareType ( const MTKBase_Feature & theFeature )

static

Returns true if theFeature is a machining bore.

Examples

machining/feature_recognizer/Program.cs.

Depth()

double cadex::Machining_Bore::Depth

(

)

const

Returns the bore depth in mm .

See also

SetDepth()

Examples

machining/feature_recognizer/Program.cs.

Radius()

double cadex::Machining_Bore::Radius

(

)

const

Returns the bore radius in mm .

See also

SetRadius()

Examples

machining/feature_recognizer/Program.cs.

SetBottom()

void cadex::Machining_Bore::SetBottom

(

const ModelData::Shape &

theBottom

)

Sets the shape for the bore bottom.

The shape can be a single face or shell.

See also

Bottom()

SetDepth()

void cadex::Machining_Bore::SetDepth

(

double

theDepth

)

Sets the bore depth in mm .

The value must be greater than zero.

See also

Depth()

SetRadius()

void cadex::Machining_Bore::SetRadius

(

double

theRadius

)

Sets the bore radius in mm .

The value must be greater than zero.

See also

Radius()

SetSidewalls()

void cadex::Machining_Bore::SetSidewalls

(

const ModelData::Shape &

theSidewalls

)

Sets the shape for bore sidewalls.

The shape can be a single face or shell.

See also

Sidewalls()

Sidewalls()

const ModelData::Shape & cadex::Machining_Bore::Sidewalls

(

)

const

Returns the shape containing the bore sidewalls.

The shape can be a single face or shell.

See also

SetSidewalls()
