cadex.Machining_TurningFace Class Reference

Describes a face with radius produced by a specified machining operation. More...

Inheritance diagram for cadex.Machining_TurningFace:

Public Member Functions
	Machining_TurningFace (global::System.IntPtr cPtr, bool cMemoryOwn)
	Machining_TurningFace ()
	Constructor.
	Machining_TurningFace (cadex.ModelData.Face theFace, cadex.Machining_FaceType theType, double theRadius)
	Creates a machining face from a ModelData.Face object, Machining_FaceType and radius.
double	Radius ()
	Returns face radius in mm .
void	SetRadius (double theRadius)
	Sets radius for face in mm.
Public Member Functions inherited from cadex.Machining_Face
	Machining_Face (global::System.IntPtr cPtr, bool cMemoryOwn)
	Machining_Face (cadex.ModelData.Face theFace, cadex.Machining_FaceType theType)
	Creates a machining face from a ModelData.Face object and Machining_FaceType.
cadex.ModelData.Face	Face ()
	Returns shape of the feature casted to ModelData.Face object.
cadex.Machining_FaceType	Type ()
	Returns type of machining face.
void	SetType (cadex.Machining_FaceType theType)
	Sets type of the machining face.
Public Member Functions inherited from cadex.MTKBase_ShapeFeature
	MTKBase_ShapeFeature (global::System.IntPtr cPtr, bool cMemoryOwn)
	MTKBase_ShapeFeature ()
	Constructor.
	MTKBase_ShapeFeature (cadex.ModelData.Shape theShape)
	Creates a feature from a ModelData.Shape object.
cadex.ModelData.Shape	Shape ()
	Returns shape of the feature.
void	SetShape (cadex.ModelData.Shape theShape)
	Sets shape of the feature.
Public Member Functions inherited from cadex.MTKBase_Feature
	MTKBase_Feature (global::System.IntPtr cPtr, bool cMemoryOwn)
void	Dispose ()
	MTKBase_Feature ()
	Constructor.
void	Nullify ()
	Resets reference to implementation object.
bool	IsNull ()
	Returns true if the object is nullified.
bool	IsEqual (cadex.MTKBase_Feature theObject)
bool	IsNotEqual (cadex.MTKBase_Feature theObject)

Static Public Member Functions
static new bool	CompareType (cadex.MTKBase_Feature theFeature)
	Returns true if theFeature is a machining turning face.
static new cadex.Machining_TurningFace	Cast (cadex.MTKBase_Feature theBase)
Static Public Member Functions inherited from cadex.Machining_Face
static new bool	CompareType (cadex.MTKBase_Feature theFeature)
	Returnstrue if theFeature is a machining face.
static new cadex.Machining_Face	Cast (cadex.MTKBase_Feature theBase)
Static Public Member Functions inherited from cadex.MTKBase_ShapeFeature
static bool	CompareType (cadex.MTKBase_Feature theFeature)
	Returnstrue if theFeature is a shape feature.
static cadex.MTKBase_ShapeFeature	Cast (cadex.MTKBase_Feature theBase)

Protected Member Functions
override void	Dispose (bool disposing)
Protected Member Functions inherited from cadex.MTKBase_ShapeFeature
override void	Dispose (bool disposing)

Detailed Description

Describes a face with radius produced by a specified machining operation.

Cutting material from workpiece by turning.

Examples

machining/feature_recognizer/Program.cs, and machining/feature_recognizer/main.cxx.

Constructor & Destructor Documentation

Machining_TurningFace() [1/2]

cadex.Machining_TurningFace.Machining_TurningFace ( )

inline

Constructor.

Machining_TurningFace() [2/2]

cadex.Machining_TurningFace.Machining_TurningFace ( cadex.ModelData.Face theFace, cadex.Machining_FaceType theType, double theRadius )

inline

Creates a machining face from a ModelData.Face object, Machining_FaceType and radius.

Constructor.

Member Function Documentation

CompareType()

static new bool cadex.Machining_TurningFace.CompareType ( cadex.MTKBase_Feature theFeature )

inlinestatic

Returns true if theFeature is a machining turning face.

Examples

machining/feature_recognizer/Program.cs.

Dispose()

override void cadex.Machining_TurningFace.Dispose ( bool disposing )

inlineprotectedvirtual

Reimplemented from cadex.Machining_Face.

Radius()

double cadex.Machining_TurningFace.Radius ( )

inline

Returns face radius in mm .

See also

SetRadius()

Examples

machining/feature_recognizer/Program.cs.

SetRadius()

void cadex.Machining_TurningFace.SetRadius ( double theRadius )

inline

Sets radius for face in mm.

The value must be more than zero.

See also

Radius()
