cadex.DFMSheetMetal_LargeDepthBeadIssue Class Reference

Describes large depth bead issue found during sheet metal design analysis. More...

Inheritance diagram for cadex.DFMSheetMetal_LargeDepthBeadIssue:

Public Member Functions
	DFMSheetMetal_LargeDepthBeadIssue (global::System.IntPtr cPtr, bool cMemoryOwn)
	DFMSheetMetal_LargeDepthBeadIssue ()
	Constructor.
	DFMSheetMetal_LargeDepthBeadIssue (cadex.SheetMetal_Bead theBead)
	Creates a large depth bead from SheetMetal_Bead object.
cadex.SheetMetal_Bead	Bead ()
	Returns the problematic bead.
void	SetBead (cadex.SheetMetal_Bead theBead)
	Sets the problematic bead.
double	ExpectedMaxDepthToSheetThicknessRatio ()
	Returns the expected maximum bead depth.
void	SetExpectedMaxDepthToSheetThicknessRatio (double theRatio)
	Sets the expected maximum bead depth.
double	ExpectedMaxDepth ()
	Return expected maximum bead depth in mm .
double	ActualDepth ()
	Return actual bead depth in mm .
double	ActualSheetThickness ()
	Returns the actual sheet thickness of analyzed part in mm .
void	SetActualSheetThickness (double theThickness)
	Sets the actual sheet thickness in mm .
Public Member Functions inherited from cadex.DFMBase_Issue
	DFMBase_Issue (global::System.IntPtr cPtr, bool cMemoryOwn)
Public Member Functions inherited from cadex.MTKBase_Feature
	MTKBase_Feature (global::System.IntPtr cPtr, bool cMemoryOwn)
void	Dispose ()
	MTKBase_Feature ()
	Constructor.
void	Nullify ()
	Resets reference to implementation object.
bool	IsNull ()
	Returns true if the object is nullified.
bool	IsEqual (cadex.MTKBase_Feature theObject)
bool	IsNotEqual (cadex.MTKBase_Feature theObject)

Static Public Member Functions
static new bool	CompareType (cadex.MTKBase_Feature theFeature)
	Returns true if theFeature is a large depth bead issue.
static new cadex.DFMSheetMetal_LargeDepthBeadIssue	Cast (cadex.MTKBase_Feature theBase)
Static Public Member Functions inherited from cadex.DFMBase_Issue
static bool	CompareType (cadex.MTKBase_Feature theFeature)
	Returnstrue if theFeature is a DFM issue.
static cadex.DFMBase_Issue	Cast (cadex.MTKBase_Feature theBase)

Protected Member Functions
override void	Dispose (bool disposing)

Detailed Description

Describes large depth bead issue found during sheet metal design analysis.

A large bead depth issue can occur when a bead is too deep. This can lead to several problems such as warping, distortion, and even cracking of the material. Additionally, a large bead depth can cause issues with the appearance of the final product.

Contains bead that fails the following condition:

\[ \large D_b \leq T \times Rt \]

\[ \begin{aligned} & \small D_b - \text{bead depth} \\ & \small T - \text{actual sheet thickness} \\ & \small Rt - \text{expected maximum bead depth to sheet thickness ratio} \end{aligned} \]

See also

DFMSheetMetal_Analyzer, DFMSheetMetal_AnalyzerParameters.MaxBeadDepthToSheetThicknessRatio(), SheetMetal_Bead

Examples

sheet_metal/dfm_analyzer/Program.cs, and sheet_metal/dfm_analyzer/main.cxx.

Constructor & Destructor Documentation

DFMSheetMetal_LargeDepthBeadIssue() [1/2]

cadex.DFMSheetMetal_LargeDepthBeadIssue.DFMSheetMetal_LargeDepthBeadIssue ( )

inline

Constructor.

DFMSheetMetal_LargeDepthBeadIssue() [2/2]

cadex.DFMSheetMetal_LargeDepthBeadIssue.DFMSheetMetal_LargeDepthBeadIssue ( cadex.SheetMetal_Bead theBead )

inline

Creates a large depth bead from SheetMetal_Bead object.

Constructor.

Member Function Documentation

ActualDepth()

double cadex.DFMSheetMetal_LargeDepthBeadIssue.ActualDepth ( )

inline

Return actual bead depth in mm .

See also

Bead()

Examples

sheet_metal/dfm_analyzer/Program.cs.

ActualSheetThickness()

double cadex.DFMSheetMetal_LargeDepthBeadIssue.ActualSheetThickness ( )

inline

Returns the actual sheet thickness of analyzed part in mm .

See also

SetActualSheetThickness()

Bead()

cadex.SheetMetal_Bead cadex.DFMSheetMetal_LargeDepthBeadIssue.Bead ( )

inline

Returns the problematic bead.

See also

SetBead()

CompareType()

static new bool cadex.DFMSheetMetal_LargeDepthBeadIssue.CompareType ( cadex.MTKBase_Feature theFeature )

inlinestatic

Returns true if theFeature is a large depth bead issue.

Examples

sheet_metal/dfm_analyzer/Program.cs.

Dispose()

override void cadex.DFMSheetMetal_LargeDepthBeadIssue.Dispose ( bool disposing )

inlineprotectedvirtual

Reimplemented from cadex.DFMBase_Issue.

ExpectedMaxDepth()

double cadex.DFMSheetMetal_LargeDepthBeadIssue.ExpectedMaxDepth ( )

inline

Return expected maximum bead depth in mm .

\[ \large D_e = T \times Rt \]

\[ \begin{aligned} & \small D_e - \text{expected maximum bead depth} \\ & \small T - \text{actual sheet thickness} \\ & \small Rt - \text{expected maximum bead depth to sheet thickness ratio} \end{aligned} \]

See also

ExpectedMaxDepthToSheetThicknessRatio(), ActualSheetThickness()

Examples

sheet_metal/dfm_analyzer/Program.cs.

ExpectedMaxDepthToSheetThicknessRatio()

double cadex.DFMSheetMetal_LargeDepthBeadIssue.ExpectedMaxDepthToSheetThicknessRatio ( )

inline

Returns the expected maximum bead depth.

See also

SetExpectedMaxDepthToSheetThicknessRatio(), DFMSheetMetal_AnalyzerParameters.MaxBeadDepthToSheetThicknessRatio()

SetActualSheetThickness()

void cadex.DFMSheetMetal_LargeDepthBeadIssue.SetActualSheetThickness ( double theThickness )

inline

Sets the actual sheet thickness in mm .

theThickness should be greater than zero.

See also

ActualSheetThickness()

SetBead()

void cadex.DFMSheetMetal_LargeDepthBeadIssue.SetBead ( cadex.SheetMetal_Bead theBead )

inline

Sets the problematic bead.

See also

Bead()

SetExpectedMaxDepthToSheetThicknessRatio()

void cadex.DFMSheetMetal_LargeDepthBeadIssue.SetExpectedMaxDepthToSheetThicknessRatio ( double theRatio )

inline

Sets the expected maximum bead depth.

theRatio should be greater than zero.

See also

ExpectedMaxDepthToSheetThicknessRatio()
